Metal honeycomb board

Basic Info.

Trademark: Huabond

Model No.: H-H119

Min thickness: 10-25mm

Max length: 3000mm

Specification: Max. 3600*2400, thickness: 20mm

Life: Long Lifespan

Technology: Laminated Stone

Application: Walls and Ceilings

Stone Variety: Granite, Basalt, Sandstone, Marble Limestone, etc.

Transport Package: Carton Box or Wooden Case

Origin: Hunan, China

4mm marble with 15mm aluminum honeycomb backer
5mm granite with 15mm aluminum honeycomb backer
4mm onyx with 10mm glass backer
3mm marble with 9mm ceramic backer

Lightweight solution! Only around 21kgs/m2
Thinnest stone veneer can be 1mm
Biggest size can be 3000x1500mm
Standard size 2400x1200mm and 1200x600mm,all sizes can be customed.
Thin stone panels can be used on exterior wall cladding, interior wall, flooring, etc.

Technical standard: GB6566-2001, Quality Supervise NO.040:

Q&A:
Q1: Will the thin stone panels easily broken?
A1: No, our thin stone panels are even stronger than solid 2cm full stone
Q2: Is this type of thin stone panels delaminate under hot and cold weather?
A2: No, we have done projects in Saudi and Norway for more than 10 years, everything is OK till now.
Q3: How to cut thin stone panels?
A3: It is same as full 20mm thick stone, can be cut easily.
Q4: How many types of finished can be done on thin stone panels?
A4: Polished, Honed, Sandblasted, Flamed, etc.
Q5: Will the thin panels bending?
A5: Yes, it will be bending under hot or cold weather, but it will be always straight after installed.
